Product Description
| Model | F-500 | F-800 | F-1000 | F-1300 | F-1600 | F-1600HL |
| Power Rating | 500Hp(373kw) | 800HP(597kw) | 1000HP(746kw) | 1300HP(969kw) | 1600HP(1193kw) | 1600HP(1193kw) |
| Rated Strake(SPM) | 165 | 150 | 140 | 120 | 120 | 120 |
| Stroke Legth | 7.5"/190.5mm | 9"/228.6mm | 10"/254mm | 12"/305mm | 12"305mm | 12"305mm |
| Gear Ratio | 4.286 | 4.185 | 4.207 | 4.206 | 4.206 | 4.206 |
| Valve Size | API5# | API6# | API6# | API7# | API7# | API7# |
| Max liner size | 6-3/4"/170mm | 6-3/4"/170mm | 6-3/4"170mm | 7"/180mm | 7"/180mm | 7"180mm |
| Max Pressure | 3945PSI(27.2Mpa) | 5000PSI(35Mpa) | 5000PSI(35Mpa) | 5000PSI(35Mpa) | 5000PSI(35Mpa) | 7500PSI(52Mpa) |
| Max Displacement | 565GPM(35.67L/S) | 617GPM(38.92L/S) | 639GPM(40.36L/S) | 737GPM(46.54L/S) | 737GPM(46354L/S) | 737GPM(46.54L/S) |
| Inlet Dia | 8"/203mm | 10"/254mm | 12"/305mm | 12"/305mm | 12"/305mm | 12"/305mm |
| Outlet Dia | 4"Flang5000psi | 5-1/8"Flang5000psi | 5-1/8"Flang5000psi | 5-1/8"Flang5000psi | 5-1/8"Flang5000psi | 5-1/8"Flang5000psi |
| Dimension L*W*H(mm) | 3658*2709*2231 | 3963*3025*2410 | 4267*3167*2580 | 4617*3260*2600 | 4615*3267*2688 | 5200*3276*2688 |
| Weight(kg) | 9770 | 14500 | 18790 | 24572 | 24791 | 28570 |
Company Details
our service
How to get an accurate quotation?
A1: The customer should provide the related technical requirements, drawings, pictures, industrial voltage, planned output, and our engineers will provide solutions and quotations in time.
Q2. How about your delivery time?
A2: Generally, it will take 35 working days after receiving your deposit payment. The specific delivery time depends on the items and the quantity of your order. Sometimes we have standard machines in stock.
Q3. after-sales service
A4: 1. Installation: Free installation and commissioning, travel expense is on foreign customer. (Including round ticket and accommodation cost) 2. Personnel training: Our engineers will give your employees free machine training when they come to your company to assemble the machines, and welcome to our factory to learn how to operate our machine
Q4. What is the warrantee period of the machine?
A3: We can supply 1 year warranty for our machines. We can provide internet or calling service at any time. We can also send engineers to your place if the production has big quality problems.
FAQ
How can I place order?
A: You can contact us by mat mail
How can I pay you?
A: After you confirm our PI, we will request you to pay. T/T (HSBC bank), L/C, D/P, Western Union are the most usual ways we are using. If you want to use other way, please tell me, we can discuss.
What’s the order procedure?
A: First we discuss order details, production details by email. Then we issue you an PI for your confirmation. You will be requested to do pr-epaid full payment or deposit before we go into production. After we get the deposit, we start to process the order. We usually need 7-15days if we don’t have the items in stock. Before production has been finished, we will contact you for shipment details, and the balance payment. After payment has been settled, we start to prepare the shipment for you.
